6.13 mm, 4 Pins, Waterproof Connectors, 5.7 mm Working Height, Pitch 2.1 mm

6.13 mm, 4 Pins, Waterproof Connectors, 5.7 mm Working Height, Pitch 2.1 mm
Category
Waterproof Connectors
Part Number P3613MP05-04A210MR
Length 6.13
Working Height 5.70
Pin Direction Vertical
Pin Tail Soldering Cup
Pin Amount 4
Pitch 2.10
Rated Current 1
Contact Resistance 50 mΩ
Get a Quotation
Lead Time 28

Product Specifications

Plunger Base Brass
Plunger Plating Nickle/Au
Barrel Base Brass
Barrel Plating Nickle/Au
Spring Base SUS
Housing PA9T
Rated Current 1 A
Rated Voltage 12 V
Contact Resistance 50 mΩ
Spring Force 50 g ± 20%
Life Cycle 10000

Description

P3613MP05-04A210MR
