ICT Test Probes | C.C.P. Contact Probes Co. Ltd.

Filters

Type

Normal Probe

Thruhole

Receptacle

Length (mm)

Min

Max

Barrel Outer Diameter (mm)

Min

Max

Tip

Receptacle, 34.5 mm, ICT Test Probes, 1.31 mm Diameter

Part Number

PR-111W5-A14

Length

34.50 mm

Barrel Outer Diameter

1.31 mm

Normal Probes, 27 mm, ICT Test Probes, 2.05 mm Diameter, 2A

Part Number

HCS089M2

Length

27.00 mm

Barrel Outer Diameter

2.05 mm

Tip

Large Blunt Awl (E)

Rated Current

2 A

Normal Probe, 38 mm, ICT Test Probes, 3.23 mm Diameter

Part Number

S-5H-0520

Length

38.00 mm

Barrel Outer Diameter

3.23 mm

Tip

Large 9 Points Serrated (H)

Normal Probe, 24.7 mm, ICT Test Probes, 0.68 mm Diameter

Part Number

P-02D-0503X

Length

24.70 mm

Barrel Outer Diameter

0.68 mm

Tip

Medium Round (D)

Normal Probe, 24.7 mm, ICT Test Probes, 1.36 mm Diameter

Part Number

P-2G2-0515

Length

24.70 mm

Barrel Outer Diameter

1.36 mm

Tip

Large Cup (A)

Receptacle, 23.5 mm, ICT Test Probes, 0.86 mm Diameter

Part Number

PR-02V-C05

Length

23.50 mm

Barrel Outer Diameter

0.86 mm

Receptacle, 29.5 mm, ICT Test Probes, 1.31 mm Diameter

Part Number

PR-111V-A14

Length

29.50 mm

Barrel Outer Diameter

1.31 mm

Normal Probe, 17.04 mm, ICT Test Probes, 1.01 mm Diameter

Part Number

P-1G1-0513

Length

17.04 mm

Barrel Outer Diameter

1.01 mm

Tip

Large Cup (A)

Receptacle, 30.1 mm, ICT Test Probes, 1.66 mm Diameter

Part Number

PR-25WV1-A09

Length

30.10 mm

Barrel Outer Diameter

1.66 mm

Receptacle, 17.4 mm, ICT Test Probes, 1.31 mm Diameter

Part Number

PR-1W2-A12

Length

17.40 mm

Barrel Outer Diameter

1.31 mm

Receptacle, 14 mm, ICT Test Probes, 0.34 mm Diameter

Part Number

PR-026RL2-C484

Length

14.00 mm

Barrel Outer Diameter

0.34 mm

Receptacle, 29.6 mm, ICT Test Probes, 2.36 mm Diameter

Part Number

SR-9W5-A09

Length

29.60 mm

Barrel Outer Diameter

2.36 mm

Receptacle, 13 mm, ICT Test Probes, 0.53 mm Diameter

Part Number

PR-038VS-C370

Length

13.00 mm

Barrel Outer Diameter

0.53 mm

Receptacle, 30.1 mm, ICT Test Probes, 1.66 mm Diameter

Part Number

PR-25WV5-A11

Length

30.10 mm

Barrel Outer Diameter

1.66 mm

Receptacle, 30.1 mm, ICT Test Probes, 1.66 mm Diameter

Part Number

PR-25WV5-A05

Length

30.10 mm

Barrel Outer Diameter

1.66 mm

Thruhole, 6.35 mm, ICT Test Probes, 0.78 mm Diameter

Part Number

CM-B1-17068-C01

Length

6.35 mm

Barrel Outer Diameter

0.78 mm

Lead Time

28

Normal Probe, 33.3 mm, ICT Test Probes, 1.01 mm Diameter, 3A

Part Number

P-111F1-0515

Length

33.30 mm

Barrel Outer Diameter

1.01 mm

Tip

Medium 4 Points Crown (F)

Rated Current

3

Lead Time

28

Normal Probe, 27.8 mm, ICT Test Probes, 1.01 mm Diameter, 3A

Part Number

CM-M1-101-17092

Length

27.80 mm

Barrel Outer Diameter

1.01 mm

Tip

Medium Sharp Awl (B)

Rated Current

1

Lead Time

28

Normal Probe, 33.3 mm, ICT Test Probes, 1.01 mm Diameter, 3A

Part Number

P-111B-0515

Length

33.30 mm

Barrel Outer Diameter

1.01 mm

Tip

Medium Sharp Awl (B)

Rated Current

3

Lead Time

28

Normal Probe, 34.1 mm, ICT Test Probes, 2.36 mm Diameter

Part Number

S-11H-0515

Length

34.10 mm

Barrel Outer Diameter

2.36 mm

Tip

Large 9 Points Serrated (H)

Lead Time

28
