3.5 mm Pogo Pin, 3 mm Working Height, P08862MP1-01A000CR
3.5 mm Pogo Pin, 3 mm Working Height, P08862MP1-01A000CR
| Category |
Single Pogo Pins
|
| Part Number | P08862MP1-01A000CR |
| Length | 3.50 |
| Working Height | 3.00 |
| Pin Direction | Vertical |
| Pin Tail | Tail |
| Pin Amount | 1 |
| Rated Current | 2 |
| Max Outer Diameter (mm) | 1.80 |
| Contact Resistance | 50 mΩ |
| Datasheet | P08862MP1-01A000CR.pdf |
| 3D CAD | P08862MP1-01A000CR.STEP |
Get a Quotation
| Lead Time | 28 |
Product Specifications
| Plunger Base | Lead Free Copper |
| Plunger Plating | Gold |
| Barrel Base | Lead Free Copper |
| Barrel Plating | Gold |
| Spring Base | SUS |
| Housing | UL94V-0 |
| Rated Current | 2 A |
| Rated Voltage | 12 V |
| Contact Resistance | 50 mΩ |
| Spring Force | 60 g ± 20% |
| Life Cycle | 10000 |
Description
This Pogo Pin can be used as a replacement pin for Mill-Max 806-22-001-004191. It can be delivered in a bag or packed in tape and reel with a cup for pick and place machines. The pin has a total height of 3.5mm (excluding the tail, height with tail 5.25mm). The barrel diameter is 1.5mm with a maximum diameter of 1.8mm at the flanch.
