8 Different Pogo Pin Types [Design & Buy] - C.C.P. Contact Probes

Filters

Single Pogo Pins

13.15mm, 1 Pin, Double Ended, 4.8mm Working Height

Part Number

P08226DH1

Length

13.15 mm

Working Height

4.80 mm

Pin Amount

1.00 Pins

Pitch

0.00

Lead Time

28

Rated Current

2

10.5mm, 1 Pin, Double Ended, 9.5mm Working Height

Part Number

P3255DH02

Length

10.50 mm

Working Height

9.50 mm

Pin Amount

1.00 Pins

Pitch

0.00

Lead Time

28

Rated Current

1

5.37mm, 1 Pin, Double Ended, 5.02mm Working Height

Part Number

P3250PH01

Length

5.37 mm

Working Height

5.37 mm

Pin Amount

1.00 Pins

Pitch

0.00

Lead Time

28

Rated Current

1

4.5mm, 1 Pin, Double Ended, 3.1mm Working Height

Part Number

P3193DP01

Length

4.50 mm

Working Height

3.10 mm

Pin Amount

1.00 Pins

Pitch

0.00

Lead Time

28

Rated Current

1

10.5mm, 1 Pin, Double Ended, 0.9mm Working Height

Part Number

P2683PH09

Length

10.50 mm

Working Height

0.90 mm

Pin Amount

1.00 Pins

Pitch

0.00

Lead Time

28

Rated Current

2

9.3mm, 1 Pin, Double Ended, 8.3mm Working Height

Part Number

P2631PH03

Length

9.30 mm

Working Height

8.30 mm

Pin Amount

1.00 Pins

Pitch

0.00

Lead Time

28

Rated Current

2

5.7mm, 1 Pin, Double Ended, 3.7mm Working Height

Part Number

P2573DP01

Length

5.70 mm

Working Height

3.70 mm

Pin Amount

1.00 Pins

Pitch

0.00

Lead Time

28

Rated Current

1

5.4mm, 1 Pin, Double Ended, 4mm Working Height

Part Number

D1838AA01

Length

5.40 mm

Working Height

4.00 mm

Pin Amount

1.00 Pins

Pitch

0.00

Lead Time

28

Rated Current

1

12mm, 1 Pin, Double Ended, 10.2mm Working Height

Part Number

D1079XX01

Length

12.00 mm

Working Height

10.20 mm

Pin Amount

1.00 Pins

Pitch

0.00

Lead Time

28

Rated Current

1

18.6mm, 1 Pin, Double Ended, 16.6mm Working Height

Part Number

D406AA01

Length

18.60 mm

Working Height

16.60 mm

Pin Amount

1.00 Pins

Pitch

0.00

Lead Time

28

Rated Current

1

6.3mm, 1 Pin, Double Ended, 4.3mm Working Height

Part Number

D172AA01

Length

6.30 mm

Working Height

4.30 mm

Pin Amount

1.00 Pins

Pitch

0.00

Lead Time

28

Rated Current

1

7.5mm, 1 Pin, 6.5mm Working Height

Part Number

H096M0-H01C000C

Length

7.50 mm

Working Height

6.50 mm

Pin Amount

1.00 Pins

Pitch

0.00

Lead Time

21

Rated Current

1

6.3 mm, 1 Pin, 5.2 mm Working Height

Part Number

N144M0-01000CR

Length

6.30 mm

Working Height

5.20 mm

Pin Amount

1.00 Pins

Pitch

0.00

Lead Time

28

Rated Current

1

4.5 mm, 1 Pin, 3.7 mm Working Height

Part Number

N103M6-01C000CR

Length

4.50 mm

Working Height

3.70 mm

Pin Amount

1.00 Pins

Pitch

0.00

Lead Time

28

Rated Current

1

6.7 mm, 1 Pin, 5.5 mm Working Height

Part Number

P2859SH01

Length

6.70 mm

Working Height

5.50 mm

Pin Amount

1.00 Pins

Pitch

0.00

Lead Time

28

Rated Current

5

2.8 mm, 1 Pin, 2.15 mm Working Height

Part Number

P5625MF01-01A000CR

Length

2.80 mm

Working Height

2.15 mm

Pin Amount

1.00 Pins

Pitch

0.00

Lead Time

28

Rated Current

1

4.8 mm, 1 Pin, 3.8 mm Working Height

Part Number

P5660MF03-01A000CR

Length

4.80 mm

Working Height

3.80 mm

Pin Amount

1.00 Pins

Pitch

0.03

Lead Time

28

Rated Current

1

13.6 mm, 1 Pin, 10.7 mm Working Height

Part Number

P2783PH01

Length

13.60 mm

Working Height

10.70 mm

Pin Amount

1.00 Pins

Pitch

0.00

Lead Time

28

Rated Current

5

9.5 mm, 1 Pin, 8.1 mm Working Height

Part Number

P6123PH03

Length

9.50 mm

Working Height

8.10 mm

Pin Amount

1.00 Pins

Pitch

0.00

Lead Time

28

Rated Current

5

4 mm, 1 Pin, 3.45 mm Working Height

Part Number

P3775FH01

Length

4.00 mm

Working Height

3.45 mm

Pin Amount

1.00 Pins

Pitch

0.00

Lead Time

28

Rated Current

1
